HONKON · OPT-MM-2000Plus

IPL platform for hair removal and skin rejuvenation

TECHNICAL SPECIFICATIONS

Working wavelength (filters):

610–1200 nm, 695–1200 nm, 640–950 nm, 615–950 nm,

530–650 nm, 530–1200 nm, 560–950 nm, 590–950 nm,

585–1200 nm, 510–950 nm, 550–650 nm, 560–1200 nm,

800–1200 nm, 420–950 nm, 430–1200 nm, 400–600 nm,

900–1200 nm, 710–1200 nm

Energy density:

10–50 J/cm²

Spot size:

8×40 mm / 15×60 mm / 10×10 mm

Pulse duration:

0.1–10 ms

Pulse interval:

0.1–10 ms

Number of pulses:

1–5T

Frequency (SHR mode):

1–10 Hz

RF energy:

5–50 W

RF exposure time:

1–4 s

RF pulse interval:

2–4 s

RF frequency:

2.64 MHz

Cooling system:

Air + water + semiconductor cooling

Power supply:

AC 110/220V ±10%, 50–60 Hz, 10А

Package dimensions:

78 × 50.5 × 142 cm

Gross weight:

60 kg
